| Display Technology |
Single 0.7” DarkChip3 DMD DLP Technology by Texas Instruments |
| Resolution |
Native XGA (1024 x 768) |
| Maximum Resolution |
UXGA (1600 x 1200) |
| Brightness (Typical) |
5000 ANSI Lumens |
| Contrast Ratio |
1200:1 (Full On/Full Off) |
| Lamp Life and Type |
Estimated at 3000/2000 Hours (STD/Bright) 350W UHP |
| Throw Ratio |
2.0-2.4:1 (Distance/Width) |
| Image Size (Diagonal) |
24.4” to 295.5” (0.62 to 7.51m) |
| Projection Distance |
3.9’ to 39.4’ (1.2 to 12m) |
| Remote Control |
Fully Featured Remote Control w/ Mouse and Laser Pointer |
| Displayable Colors |
134.2 million |
| Audio |
Two 5-Watt Speakers |
| Aspect Ratio |
4:3 Native, 16:9 and 16:10 Compatible |
| Computer Compatibility |
UXGA, SXGA+, XGA, SVGA, VGA, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p) |
| Projection Lens |
F= 2.0~2.16, f = 28.5~34.1 mm, 1.2x Motorized Zoom and Focus |
| Lens Shift (Powered) |
Vertical ±110% Offset (±60% Image Height) Horizontal ±75% Offset (±25% Image Width) |
| Keystone Correction |
±40° Vertical, ±15° Horizontal |
| Horizontal Scan Rate |
15 to 100 KHz |
| Vertical Refresh Rate |
43 to 87 Hz |
| User Controls |
Complete On Screen Menu Adjustments in 21 Languages |
| Monitor Loop Through |
D-Sub 15-Pin VGA Output (Functional in Both Normal and Standby Modes) |
| I/O Connectors |
HDMI (Audio Supported), DVI-D w/HDCP, Two VGA-In, VGA-Out, S-Video, Composite Video, Five BNC (RGBHV/YPbPr), Six Mini-Jack Audio-In, Audio-Out, USB, RS-232, RJ45, +12V Trigger |
| Security |
Kensington Lock Port, Password Protection |
| Projection Method |
Front, Rear, Ceiling Mount, Table Top |
| Uniformity |
85% |
| Weight |
21 lbs (9.5kg) |
| Dimensions (W x H x D) |
15.7” x 6.6” x 18.7” (398 x 167 x 475 mm) |
| Noise Level (STD/Bright) |
30dB/32dB |
| Operating Temperature |
41° to 95°F (5° to 35°C), 80% Max Humidity, Adjustable Fan Speed for High Altitude Application |
| Power Supply |
AC Input 100-240V, Auto-Switching |
| Power Consumption |
410 Watts (Maximum), |
| Standard Accessories |
AC Power Cord, VGA to VGA Cable, USB Cable, RS-232 Cable, Remote Control, Batteries for Remote, Lens Cap, Quick Start Card, CD-ROM User’s Manual and Warranty Card |
| Optional Accessories |
Wireless Module, Composite Video Cable, S-Video Cable, HDMI Cable, DVI Cable, Audio-Out Adapter and Panoview Series Screens |
| Warranty |
90 Days Pars & Labor, 30 Days on Lamp |
