| Display Technology |
Single 0.65” DMD DLP Technology by Texas Instruments |
| Resolution |
Native WXGA (1280 x 800) |
| Maximum Resolution |
WUXGA (1920 x 1200) |
| Brightness (Typical) |
2700 ANSI Lumens |
| Contrast Ratio |
2000:1 (Full On/Full Off) |
| Lamp Life and Type |
Estimated at 3000/4000 Hours (STD/ECO) 200W UHP |
| Throw Ratio |
1.55-1.70:1 (Distance/Width) |
| Image Size (Diagonal) |
32.8” to 359.4” (0.83 to 9.12m) |
| Projection Distance |
3.9’ to 39.4’ (1.2 to 12m) |
| Remote Control |
Fully Featured Remote Control w/ Mouse and Laser Pointer |
| Displayable Colors |
16.7 Million |
| Audio |
One 2-Watt Speaker |
| User Controls |
Complete On Screen Menu Adjustments in 22 Languages |
| Keystone Correction |
± 16º Vertical |
| Computer Compatibility |
VGA, SVGA, XGA, WXGA, SXGA+, WXGA+, UXGA, WUXGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (576i/p, 720p, 1080i/p) |
| Uniformity |
85% |
| Aspect Ratio |
16:10 Native, 4:3, 5:4 & 16:9 Compatible |
| Projection Lens |
F = 2.41~2.55, f = 21.79~23.99mm, 1.10X Manual Zoom and Focus |
| Monitor Loop Through |
D-Sub 15 VGA Output (Functional in Both Normal and Standby Modes) |
| I/O Connectors |
DVI-I w/HDCP,VGA-In, S-Video, VGA-Out, Audio-In, USB, RS-232 |
| Security |
Kensington® Lock Port |
| Projection Method |
Front, Rear, Ceiling Mount, Table Top |
| Weight |
4.4 lbs (1.8 kg) |
| Dimensions (W x H x D) |
10.2” x 2.9” x 7.4” (259 x 73 x 188 mm) |
| Noise Level (STD/ECO) |
33dB/31dB |
| Horizontal Scan Rate |
31.5 to 100 kHz |
| Vertical Refresh Rate |
47 to 85 Hz |
| Power Supply |
AC Input 100-240V, Auto-Switching |
| Power Consumption |
270 Watts (Maximum), |
| Operating Temperature |
40-95º F (5-35º C) (80% Humidity), Adjustable Fan Speed for High Altitude Application |
| Standard Accessories |
AC Power Cord, VGA to VGA Cable, VGA to Component Adapter, DVI to HDMI Adapter, Remote Control, Batteries for Remote, Carrying Case, Quick Start Guide, Warranty Card and User’s Manual |
| Optional Accessories |
Ceiling Mount, S-Video Cable, Composite Video to S-Video Adapter, DVI to DVI Cable, Audio-Out Adapter, Gold Service Warranty and Panoview™ Series Screens |
| Warranty |
90 Days Limited Parts and Labor, 30 Days on Lamp |
|
