| Display Technology |
0.55” DLP® Technology by Texas Instruments |
| Resolution |
Native SVGA (800 x 600) |
| Maximum Resolution |
UXGA (1600 x 1200) Resized |
| Brightness (Typical) |
2200 Lumens |
| Contrast Ratio |
2000:1 (Full On/Full Off) |
| Lamp Life and Type |
Estimated at 2000/3000 Hours (STD/ECO)
180W UHP |
| Throw Ratio |
1.94 to 2.16:1 (Distance/Width) |
| Image Size (Diagonal) |
27.5” to 302.9” (0.6 to 7.69 m) |
| Projection Distance |
3.9’ to 39.4’ (1.2 to 12 m) |
| Noise Level |
32dB/30dB (STD/ECO) |
| Audio |
One 1-Watt Speaker |
| Displayable Colors |
16.7 Million |
| Uniformity |
85% |
| Keystone Correction |
± 40º Vertical |
| Computer Compatibility |
VGA, SVGA, XGA, SXGA, SXGA+, UXGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
NTSC, PAL, SECAM, EDTV (480p), HDTV (576i/p, 720p, 1080i) |
| Monitor Loop Through |
D-Sub 15 VGA Output (Functional in Both Normal and Standby Modes) |
| Remote Control |
Fully Featured Remote w/ Laser Pointer |
| User Controls |
Complete On Screen Menu Adjustments in 11 Languages |
| Aspect Ratio |
4:3 Native, 1.78:1, 5:4 and 16:9 Compatible |
| Projection Lens |
F = 2.35~2.47, f = 21.83~23.81mm,
1.1x Manual Zoom and Focus |
| I/O Connectors |
DVI w/HDCP, VGA-In, VGA-Out, S-Video, Audio-In, RS-232, USB |
| Security |
One Kensington® Lock Port |
| Projection Method |
Front, Rear, Ceiling Mount, Table Top |
| Horizontal Scan Rate |
15 to 100 kHz |
| Vertical Refresh Rate |
43 to 85 Hz |
| Weight |
4.4 lbs (2.0 kg) |
| Dimensions (W x H x D) |
10.2” x 2.8” x 7.4” (259 x 73 x 188 mm) |
| Operating Temperature |
40-95°F (5-35°C) (80% Humidity), Adjustable Fan Speed for High Altitude Application |
| Power Supply |
AC Input 100 - 240V, Auto-Switching |
| Power Consumption |
260 Watts (Maximum), <10 Watts (Standby Power) |
| Standard Accessories |
AC Power Cord, VGA to VGA Cable, Remote Control, Batteries for Remote, Lens Cap, Quick Start Guide, Warranty Card, User’s Manual and Carrying Case |
| Optional Accessories |
Ceiling Mount, VGA to Component Cable, RS-232 Cable, S-Video Cable, S-Video to Composite Adapter, Composite Video Cable, and Audio-Out Adapter |
| Warranty |
90 Days Parts and Labor, 30 Days on Lamp |
